HYDRO-ROCKET
INTRODUCTION :-
It is the event where you have the chance to show case your rocketry skills. Experience the fun in true engineering while working with rocket propulsion and aerodynamic. One of the most fun events, it will surely leave you missing it once it's over. The purpose of here is to design and manufacture a water rocket . A water rocket is a type of model rocket using water as its reaction mass. The pressure vessel- the engine of the rocket is usually a used plastic soft drink bottle. The water is forced out by a pressurized gas, typically compressed air. It is an example of Newton's third law of motion. It covers various aspects of product making including design, model constructions.
ROUNDS INVOLVED:-
1. Range covered.
2. Time of flight.
ROUND 1
The main objective of this round is to launch a water-rocket without any payload, and make it go as far as possible from the launch point i.e. the maximum horizontal distance. The horizontal distance will be considered from the starting point to the point where any part of the rocket first touches the ground. Multi-stage rockets are also allowed but the combined tank capacity must be 2 liters only. Each team shall be allowed three attempts to launch and the better of the three will be considered. (This may be altered later based on the performance of the teams).
NOTE:-
Pressure limit for this round will be 60 psi. Only 30 percent of the candidates appearing in first round will be qualifying into the second round which depends upon the score they get.
ROUND 2
This round the teams whose rocket will remain in air for maximum time will get maximum point. The participant can fill up to any pressure and release his rocket. The time of flight is calculated. The more is the time of flight more will be the points he scores. Only two attempts will be given to each participants in this round.
RULES AND REGULATIONS:-
A team may consists of a maximum of 2 members. Team may be different rockets of different rounds. The rocket may be built completely scratch and not using model rocketry parts. The pressure vessel must be made from commercially available non metallic soda bottles (PET bottles). Fins if required are to be constructed from lightweight non metallic materials. The rocket must use tap water as its primary reaction mass. Thrust must come from expelling reaction mass/water, not from air discharge. Participants will be provided with tap water. The angle at which the rocket is to be launched can be decided by the participant. The organizer will not provide a launcher, so team must bring their own launcher. The rocket must use compressed air as its energy source. A normal bicycle pumps well as a foot pump will be provided to compressed air. The size of the pump outlet will be the standard type available in the market. If your design has a different nozzle size, please be sure to bring your own nozzle and connected pipe. All parts if the rocket should be properly attached to the a main body .If any parts (fins etc.) breaks away during flight, it will comprise the safety of the spectators. Therefore, such water rockets may be disqualified from further participation at the discretion of the organizers. Each team is strongly advised to bring two rockets of the same design (the second acting as a backup) in case of any damage. The organizers will not be responsible for any damage suffered by rockets during the competition. Extra time shall not be given for remaking of damaged rockets.
JUDGEMENT CRITERIA:-
The final Judgement is based on the total points scored by the participated team in all the two rounds described above The points are also given to the teams based on their creativity and simplicity in making the water propelled rockets, this will be the decided at the time of the event by the event manager by viewing their rocket samples. The total points scored in all the three rounds are added up and awarded as their final score.
REGISTRATION FEE:-
"For each team Rs 300/- only and 200/- per head."
For further details contact:-
PAVAN SAI : 7997620067
mail to:- hydrorocket.sanketa2k20@gmail.com
Have you ever dreamt of flying your own fuel powered rocket which is simple, safe & exciting? This we bring you the ideal platform for showcasing your understanding of fluid dynamics with the event HYDRO ROCKET. A rocket to shoot up into the sky to grab exciting cash prize in store. This tests the participants creativity in applying the effects of drag force on a dynamic domain & come up with clean, safe & novel design of rockets powered by simple fuels such as water (H2O). Balance between speed and control is just what is desired to design the Neolithic multi-stage propulsion.
ABOUT:-It is the event where you have the chance to show case your rocketry skills. Experience the fun in true engineering while working with rocket propulsion and aerodynamic. One of the most fun events, it will surely leave you missing it once it's over. The purpose of here is to design and manufacture a water rocket . A water rocket is a type of model rocket using water as its reaction mass. The pressure vessel- the engine of the rocket is usually a used plastic soft drink bottle. The water is forced out by a pressurized gas, typically compressed air. It is an example of Newton's third law of motion. It covers various aspects of product making including design, model constructions.
ROUNDS INVOLVED:-
1. Range covered.
2. Time of flight.
ROUND 1
The main objective of this round is to launch a water-rocket without any payload, and make it go as far as possible from the launch point i.e. the maximum horizontal distance. The horizontal distance will be considered from the starting point to the point where any part of the rocket first touches the ground. Multi-stage rockets are also allowed but the combined tank capacity must be 2 liters only. Each team shall be allowed three attempts to launch and the better of the three will be considered. (This may be altered later based on the performance of the teams).
NOTE:-
Pressure limit for this round will be 60 psi. Only 30 percent of the candidates appearing in first round will be qualifying into the second round which depends upon the score they get.
ROUND 2
This round the teams whose rocket will remain in air for maximum time will get maximum point. The participant can fill up to any pressure and release his rocket. The time of flight is calculated. The more is the time of flight more will be the points he scores. Only two attempts will be given to each participants in this round.
RULES AND REGULATIONS:-
A team may consists of a maximum of 2 members. Team may be different rockets of different rounds. The rocket may be built completely scratch and not using model rocketry parts. The pressure vessel must be made from commercially available non metallic soda bottles (PET bottles). Fins if required are to be constructed from lightweight non metallic materials. The rocket must use tap water as its primary reaction mass. Thrust must come from expelling reaction mass/water, not from air discharge. Participants will be provided with tap water. The angle at which the rocket is to be launched can be decided by the participant. The organizer will not provide a launcher, so team must bring their own launcher. The rocket must use compressed air as its energy source. A normal bicycle pumps well as a foot pump will be provided to compressed air. The size of the pump outlet will be the standard type available in the market. If your design has a different nozzle size, please be sure to bring your own nozzle and connected pipe. All parts if the rocket should be properly attached to the a main body .If any parts (fins etc.) breaks away during flight, it will comprise the safety of the spectators. Therefore, such water rockets may be disqualified from further participation at the discretion of the organizers. Each team is strongly advised to bring two rockets of the same design (the second acting as a backup) in case of any damage. The organizers will not be responsible for any damage suffered by rockets during the competition. Extra time shall not be given for remaking of damaged rockets.
JUDGEMENT CRITERIA:-
The final Judgement is based on the total points scored by the participated team in all the two rounds described above The points are also given to the teams based on their creativity and simplicity in making the water propelled rockets, this will be the decided at the time of the event by the event manager by viewing their rocket samples. The total points scored in all the three rounds are added up and awarded as their final score.
REGISTRATION FEE:-
For further details contact:-
PAVAN SAI : 7997620067
mail to:- hydrorocket.sanketa2k20@gmail.com
ENGINE ASSEMBLY
Description of event:-
Assembling each and every part of the given engine in given time or earlier.
Topic:- Assembling.
Rules and regulations:-
Assembling each and every part of the given engine in given time or earlier.
Topic:- Assembling.
Rules and regulations:-
- Four members per each team.
- "Registered fee will not be given back."
- The judgement depends only on the event organisers. The description of final judgement will not be explained to anyone.
Works of Participants:-
Attending screening test, listening the description of engine assembly & to participate in engine assembly.
Judgement criteria:-
Time taken to assemble the engine, the team which assembles in less time gets first position.
Registration fee:-
"100/- per head
For further information:
NARENDRA
9704102558
Mail to:-
engineassembly.sanketa2k20@gmail.com
TRUSS CHAMP
The main objective of this event is to build a strong, light and aesthetically design bridge with Popsicle sticks.
GUIDE LINES:-
1. Form a team of two members. It costs 300/- per team.
2. Only wooden Popsicle sticks (10 cm height,8 Cm width) and water based glue such as Elmers may be used to make your bridge. You can cut and shape them anyway.The length of the Bridge structure must be 60cm.
3.A car must be able to roll from one end to other. In other words, your bridge must actually be a bridge.
4. Please remember that the load testing may results in the destruction of bridge. We don't know what the maximum load your bridge can hold until it breaks. Decoration and paintings are allowed, but the judge will decide if any additions (other than those made from pop sticks) result in an unfair advantage to a bridge entered for load testing.
5. The bridge must accept the test load block in the centre of the span on the road bed surface, must be able to receive the test load from testing apparatus. If this is not possible for reasons related to the design of the bridge, test load block may place any top of the trusses, beams, supports or roof structures.
6. A bridge will be considered to have failed under the test load if the bridge member breaks, fractures, cracks separates from any attachment or joint, resulting in the collapse of bridge.
JUDGEMENT CRITERIA:-
Considering two aspects:
1) EFFECIENCY:
Ratio of ultimate load bridge to bridge weight.
2) AESTHETIC DESIGN:
Bridge should be flat and with uneven surface inside it and its design should be good.
Registration fee:-
300/- for a Team of 2 members or 200/- per head
Contact:-
PAVAN SAI.,
Mobile:+91 7997620067
Reference Mail
trusschamp.sanketa2k20@gmail.com
GUIDE LINES:-
1. Form a team of two members. It costs 300/- per team.
2. Only wooden Popsicle sticks (10 cm height,8 Cm width) and water based glue such as Elmers may be used to make your bridge. You can cut and shape them anyway.The length of the Bridge structure must be 60cm.
3.A car must be able to roll from one end to other. In other words, your bridge must actually be a bridge.
4. Please remember that the load testing may results in the destruction of bridge. We don't know what the maximum load your bridge can hold until it breaks. Decoration and paintings are allowed, but the judge will decide if any additions (other than those made from pop sticks) result in an unfair advantage to a bridge entered for load testing.
5. The bridge must accept the test load block in the centre of the span on the road bed surface, must be able to receive the test load from testing apparatus. If this is not possible for reasons related to the design of the bridge, test load block may place any top of the trusses, beams, supports or roof structures.
6. A bridge will be considered to have failed under the test load if the bridge member breaks, fractures, cracks separates from any attachment or joint, resulting in the collapse of bridge.
JUDGEMENT CRITERIA:-
Considering two aspects:
1) EFFECIENCY:
Ratio of ultimate load bridge to bridge weight.
2) AESTHETIC DESIGN:
Bridge should be flat and with uneven surface inside it and its design should be good.
Registration fee:-
300/- for a Team of 2 members or 200/- per head
Contact:-
PAVAN SAI.,
Mobile:+91 7997620067
Reference Mail
trusschamp.sanketa2k20@gmail.com
ROBO-RACE
DESCRIPTION:-
Since childhood we always fancied the playing of RC controlled car and some of us retained the zeal to participate at regional & national level. We at Sanketa2k20 have designed a competent court where you get to test the efficiency & manoeuvrability of bot while traversing your goals with joy. Brace yourselves, goal all the balls and emerge as the winner.
RULES AND REGULATIONS:-
1. The team may consists maximum of two members.
2. Students from different colleges can form as a team.
3.During the game, one member will control the robot and other one gives support, teams are allowed to switch members in different rounds.
4. If the bot is proved to be inactive for more than 60 seconds, it is disqualified.
5. The judgment criteria of this event is based on the points scored by the bot.
6. The judgement of winners and the decisions will be finalised by the management team and judges.
7. Any team violating the rules and regulations may considered as disqualified and will be eliminated.
8. The bot dimensions is 30*30*30 cm and ready made bots are not allowed.
9. The path may contains wet mud,dry mud, pebbles, fire, grease etc..
REGISTRATION FEE :-
Rs.350/- per team and 250/- per head
Maximum No. of participants in a team is 2.
COMBO:-
ROBO RACE+ROBO SOCCER= Rs.600/-
BOT SPECIFICATIONS:-
1. The battery used cannot exceed 12 V.
2. The power supply may / may not be on the board.
3. Bot should not exceed 30 cms..
CONTACT US ON :
ABHINAV.
Ph.No:- 8639209138
E-mail:-
roborace.sanketa2k20@gmail.com
Since childhood we always fancied the playing of RC controlled car and some of us retained the zeal to participate at regional & national level. We at Sanketa2k20 have designed a competent court where you get to test the efficiency & manoeuvrability of bot while traversing your goals with joy. Brace yourselves, goal all the balls and emerge as the winner.
RULES AND REGULATIONS:-
1. The team may consists maximum of two members.
2. Students from different colleges can form as a team.
3.During the game, one member will control the robot and other one gives support, teams are allowed to switch members in different rounds.
4. If the bot is proved to be inactive for more than 60 seconds, it is disqualified.
5. The judgment criteria of this event is based on the points scored by the bot.
6. The judgement of winners and the decisions will be finalised by the management team and judges.
7. Any team violating the rules and regulations may considered as disqualified and will be eliminated.
8. The bot dimensions is 30*30*30 cm and ready made bots are not allowed.
9. The path may contains wet mud,dry mud, pebbles, fire, grease etc..
REGISTRATION FEE :-
Rs.350/- per team and 250/- per head
Maximum No. of participants in a team is 2.
COMBO:-
ROBO RACE+ROBO SOCCER= Rs.600/-
BOT SPECIFICATIONS:-
1. The battery used cannot exceed 12 V.
2. The power supply may / may not be on the board.
3. Bot should not exceed 30 cms..
CONTACT US ON :
ABHINAV.
Ph.No:- 8639209138
E-mail:-
roborace.sanketa2k20@gmail.com
ROBO-SOCCER
DESCRIPTION:-
Since childhood we always fancied the playing of RC controlled car and some of us retained the zeal to participate at regional & national level. We, at Sanketa2k20 have designed a competent court where you get to test the efficiency & maneuverability of bot while traversing your goals with joy.Brace yourselves,goal all the balls and emerge as the winner.
RULES AND REGULATIONS:-
1. The team may consists maximum of two members.
2. Students from different colleges can form as a team.
3. During the game, one member will control the robot and other one gives support, teams are allowed to switch members in different rounds.
4. If the bot is proved to be inactive for more than 60 seconds, it is disqualified.
5. The judgment criteria of this event is based on the points scored by the bot.
6. The judgement of winners and the decisions will be finalised by the management team and judges.
7. Any team violating the rules and regulations may considered as disqualified and will be eliminated.
8. The bot dimensions is 30*30*30 cm and ready made bots are not allowed.
REGISTRATION FEE :-
Rs.350/- per team and 250 per head
Maximum No. of participants in a team is 2.
COMBO:-
ROBO RACE+ROBO SOCCER= Rs.600/-
BOT SPECIFICATIONS:-
1. The battery used cannot exceed 12 V.
2. The power supply may / may not be on the board.
CONTACT US ON :
ABHINAV.
Ph.No:- 8639209138
E-mail:-
roborace.sanketa2k20@gmail.com
Since childhood we always fancied the playing of RC controlled car and some of us retained the zeal to participate at regional & national level. We, at Sanketa2k20 have designed a competent court where you get to test the efficiency & maneuverability of bot while traversing your goals with joy.Brace yourselves,goal all the balls and emerge as the winner.
RULES AND REGULATIONS:-
1. The team may consists maximum of two members.
2. Students from different colleges can form as a team.
3. During the game, one member will control the robot and other one gives support, teams are allowed to switch members in different rounds.
4. If the bot is proved to be inactive for more than 60 seconds, it is disqualified.
5. The judgment criteria of this event is based on the points scored by the bot.
6. The judgement of winners and the decisions will be finalised by the management team and judges.
7. Any team violating the rules and regulations may considered as disqualified and will be eliminated.
8. The bot dimensions is 30*30*30 cm and ready made bots are not allowed.
REGISTRATION FEE :-
Rs.350/- per team and 250 per head
Maximum No. of participants in a team is 2.
COMBO:-
ROBO RACE+ROBO SOCCER= Rs.600/-
BOT SPECIFICATIONS:-
1. The battery used cannot exceed 12 V.
2. The power supply may / may not be on the board.
CONTACT US ON :
ABHINAV.
Ph.No:- 8639209138
E-mail:-
roborace.sanketa2k20@gmail.com
MODEL EXPO
INTRODUCTION
model Expo is a Event in which you have to exhibit your Technical and Non-technical working or Prototype models. You will be competing with people from different colleges and You can share your idea to Thousands of Students in the Arena .
JUDGEMENT CRITERIA:-
The best model will be judged based upon the Unique idea, Concept and Real time possibility of the Model .
REGISTRATION FEE:
300/-per team and 200/- per head
Contact
SIVA SURYA,
Mobile:
8555050240
Reference Mail:
modelexpo.sanketa2k20@gmail.com
model Expo is a Event in which you have to exhibit your Technical and Non-technical working or Prototype models. You will be competing with people from different colleges and You can share your idea to Thousands of Students in the Arena .
JUDGEMENT CRITERIA:-
The best model will be judged based upon the Unique idea, Concept and Real time possibility of the Model .
REGISTRATION FEE:
300/-per team and 200/- per head
Contact
SIVA SURYA,
Mobile:
8555050240
Reference Mail:
modelexpo.sanketa2k20@gmail.com
TECH VILLA
PPT
While ideas can be great, they need to be presented in a way they can be appreciated and implemented.
This is the platform to expose your talent and in-depth knowledge on your interested areas. Come, chill out the hearts of the people with your innovative presentation.
RULES AND REGULATIONS:-
1. Abstract should be in IEEE format and not to exceed ONE PAGE and presentation should not exceed 15 slides.
2. Bring 2 hard copies and 1 soft copy of the submitted topic on the day of event.
3. Bring a pen drive containing your power point presentation.
4. Participant should deliver the seminar not more than 10 minutes.
5. Mail your abstract, paper,and presentation slides before 16th Feb,2020 to techvilla.sanketa2k20@gmail.com
6. Selection will be intimated through mail.
CASH PRIZE:2000/-
MAXIMUM number of participants in a team is 2.
JUDGEMENT CRITERIA::
The main aspects that are considerable:
1. Way of presentation.
2. Participant attitude.
3. Good knowledge in the topic.
REGISTRATION FEE:-
Registration fee is 300/- for the team of Two members and 200/- per head.
FOR FURTHER INFORMATION :
Contact :-
Ch.CHAITANYA
contact no.:6305267986
Refer mail: techvilla.sanketa2k20@gmail.com
RULES AND REGULATIONS:-
1. Abstract should be in IEEE format and not to exceed ONE PAGE and presentation should not exceed 15 slides.
2. Bring 2 hard copies and 1 soft copy of the submitted topic on the day of event.
3. Bring a pen drive containing your power point presentation.
4. Participant should deliver the seminar not more than 10 minutes.
5. Mail your abstract, paper,and presentation slides before 16th Feb,2020 to techvilla.sanketa2k20@gmail.com
6. Selection will be intimated through mail.
CASH PRIZE:2000/-
Theme:OPEN
TEAM CAPACITY:-MAXIMUM number of participants in a team is 2.
JUDGEMENT CRITERIA::
The main aspects that are considerable:
1. Way of presentation.
2. Participant attitude.
3. Good knowledge in the topic.
REGISTRATION FEE:-
Registration fee is 300/- for the team of Two members and 200/- per head.
FOR FURTHER INFORMATION :
Contact :-
Ch.CHAITANYA
contact no.:6305267986
Refer mail: techvilla.sanketa2k20@gmail.com
CAD MANIC
This event is truly an epic experience for CAD drafter's and designers. Computer-aided design and drafting (CADD) software
replaces manual drafting with greater speed and accuracy. Cad manic is an event to evaluate the drafting, modelling
skills of the students in part modelling to design and analysis.
It's time to fire up your imagination and creativity, so Aiming to test imagination of designers. This CAD MANIC is about testing the brilliance of solid modelling and detailing a structure in AutoCAD (3D).
Now the clash has began so boot up your modelling intelligences and shine your skills and get ready with your tricks.
JUDGEMENT CRITERIA:-
1.Least Time With Efficient Drawing
Registration fee:-
"100/- per head
For further information:
NARENDRA
9704102558
Mail to:-
cadmanic.sanketa2k20@gmail.com
It's time to fire up your imagination and creativity, so Aiming to test imagination of designers. This CAD MANIC is about testing the brilliance of solid modelling and detailing a structure in AutoCAD (3D).
Now the clash has began so boot up your modelling intelligences and shine your skills and get ready with your tricks.
JUDGEMENT CRITERIA:-
1.Least Time With Efficient Drawing
Registration fee:-
"100/- per head
For further information:
NARENDRA
9704102558
Mail to:-
cadmanic.sanketa2k20@gmail.com
